Manual Forcible Entry Rescue Tool

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1645

Introduction of Manual Forcible Entry Rescue Tool

Manual forcible entry rescue tool is used for the forcible entry of concrete, walls, doors and Windows.

Applicable places: fires, earthquake, armed police, public security and other rescue operations.

Parameter of Manual Forcible Entry Rescue Tool

Original Length	630mm
Stretching Length	960mm
Weight (whole set)	12.6kg
Dimension	800mm*450mm*125mm
Weight	Joystick 4kg Chopping Bit 3.5kg
Material	Alloy Casting

Pictures of Manual Forcible Entry Rescue Tool

Compressed Portable Air Breathing Apparatus

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1581

Introduction of Compressed Portable Air Breathing Apparatus

There are 2 carbon fiber composite air cylinders. The storage volume is larger and the service time is long.

Compressed Portable Air Breathing Apparatus is particularly applicable to rescue occasions.

1. Quick transformation from double-cylinder to single-cylinder

2. If there is no backup air cylinder on disaster site, then the Y-joint of the Reducer can be

Demount ed manually to make it renovated into a single-cylinder air breathing apparatus.

3. The configuration can be 4.7L/6.8L .

Parameter of Compressed Portable Air Breathing Apparatus

Volume of       cylinder	pressure cylinder	Respiratory resistance		Alarm pressure	Weight (lightest configuration)	Service time
		Exhalation	Inhalation
4.7L*2	≤30MPa	≤1000Pa	≤500Pa	5.5±0.5M Pa	11.1KG	90 min
6.8L*2	≤30MPa	≤1000Pa	≤500Pa	5.5±0.5M Pa	11.9KG	136min

Pictures of Compressed Portable Air Breathing Apparatus

CDH-Y Train Hydraulic Buffer Stop

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1521

Introduction of CDH-Y Train Hydraulic Buffer Stop

1 CDH-Y Train Hydraulic Buffer Stop parameter technical:
1.1 The center of the buffer head to the rail surface height:
For the standard rail vehicles: 850±10mm
For the subway, light rail and other vehicles:500±10mm, 660±10mm,678±10mm,720±10mm
Other height can be designed as the car coupler which provides by customer
1.2 The size and the shape of the buffer head
For the standard rail vehicles:480*250mm flat shape
For the subway, light rail and other vehicles:This is matched with the size and the shape of the car coupler
1.3 The allowing impact speed of the vehicle:There are 4 classes according with the structural strength
Class one:CDH-Y-15 type:V≤15km/h
Class two:CDH-Y-20 type V≤20km/h
Class three :CDH-Y-25 type V≤25km/h
Class four:CDH-Y-30 type V≤30km/h
1.4 The level of total resistance(F) of the stop buffer:There are 3 classes according to different dampers:
Class one:2 couples of the dampers: F≥30t
Class two:3 couples of the dampers: F≥45t
Class three: 4 couples of the dampers: F≥60t
1.5 After being impacted by the vehicle,the slid distance of the buffer stop ,please see attachment .

Parameter of CDH-Y Train Hydraulic Buffer Stop

CDH-Y tppe	The center of the buffer head to the  rail surface height	The size and the shape  of the buffer head
For the standard rail vehicles	850±10mm	480*250mm flat shape
For the subway, light rail  and other vehicles	500±10mm, 660±10mm, 678±10mm,720±10mm	This is matched with the size  and the shape of the car coupler

Pictures of CDH-Y Train Hydraulic Buffer Stop

Portable Firefighting Hydraulic Door Opener

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1644

Introduction of Portable Firefighting Hydraulic Door Opener

1-Material: Base angle taken use of special steel manufactured. Can provide great opening force;
2-Function: Open Door & Gate etc. when emergency happened;
3-Applications:accident rescue, especially suitable for residential and commercial buildings, hotels & fire rescue to open the locked door in time.

Features of Portable Firefighting Hydraulic Door Opener

1. Provides 10 tons collapsing force for opening the door; working with both big and small manual pump with self-locking functions;
2. Safe to work in the explosive place, no spark during operation;
3. Mini sized, easy to bring, can be stored in the metal cabinet, implementing rapid mobility aid.

Parameter of Portable Firefighting Hydraulic Door Opener

Model	ZM-130/100
Rated Working Pressure	63MPa(630bar/9135PSI)
Max. Opening Force	100KN(10Tons/22477Lbs)
Closing Length	≤228mm
Opening Height	120mm
Times of Hand Pump Beating When Start without Load	≤20times
Closing Time Without Load(Free Fall)	≤50s
Weight	≤5.5kg
Dimension(L*W*H)	122*100*228mm

Pictures of Portable Firefighting Hydraulic Door Opener

6.8L Air Breathing Respirator

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1580

Introduction of 6.8L Air Breathing Respirator

1.Light, comfortable and close-fitting vest-style respirator

2.There is 1 carbon fiber or steel air cylinder with the working pressure of 30MPa

3.PG-S Pressure Gauge and high-decibel Alarm are provided at breast.

4.The vest, which is made from KEVLAR material, has good flame resistant and anti-tear performance.

5.Direct fire rescue to a maximum extent and guarantee the safety of fire fighters. The work efficiency of fire rescue is greatly improved.

6.The service time is about 30min for 3L cylinder,20 min for 2L and different durable time with different volume cylinder.

Parameter of 6.8L Air Breathing Respirator

Type	Cylinder volume(L)	Cylinder pressure(Mpa)	Max.air volume of(L) cylinder (L)	Air supply flow >L/min	Warning Pressure(MPa)	Use time (min)	Apparatus weight(kg)	Package Dimensions(cm) (cm)
RHZK-5/30	5	30	1500	300	5~6	50	≤12	77×30×48
RHZK-6/30	6	30	1800	300	5~6	60	≤14	77×30×48
RHZKF-2/30	2	30	600	300	5~6	20	≤4	77×30×48
RHZKF-3/30	3	30	900	300	5~6	30	≤4.5	77×30×48
RHZKF-6.8/30	6.8	30	2040	300	5~6	60	≤8.5	77×30×48
RHZKF-6.8X2/30	13.6	30	4080	300	5~6	120	≤14.5	77×30×48
RHZKF-9/30	9	30	2700	300	5~6	90	≤11.5	77×30×48

Pictures of 6.8L Air Breathing Respirator

DJQ-II Handle Rails Bilateral Chamfer Tool

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1520

Introduction of DJQ-II Handle Rails Bilateral Chamfer Tool

DJQ-II Handle Rails Bilateral Chamfer Tool is a special tool being used to eliminate stress concentration at point angle spot after rail drilling operation. It features double faced chamfering, compact structure, easy manipulation, small size and light weight, and portability. It’s an indispensable tool used in rail drilling operation.

Parameter of DJQ-II Handle Rails Bilateral Chamfer Tool

Max. chamfering diameter	32
Max. chamfering cutting torque	Tmax=10N*m
working efficiency	10s/group
Max.handle moving force	Fmax=55N(L=180)
weight	2Kg

Pictures of DJQ-II Handle Rails Bilateral Chamfer Tool

Hydraulic Rescue Telescopic Ram

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1643

Introduction of Hydraulic Rescue Telescopic Ram

Hydraulic rescue telescopic ram uses with electric pump or hand pump, hold the top function can be realized. In the event of fire or earthquake, it is used to protect rescuers and victims within dangerous buildings by propping or fixing dangerous objects before entry for rescue operations. In the case of traffic accident, it can be used to hold up or put up different parts of the involved vehicle as necessary. Two different models of this series can be used in relay to open a passage for rescue screw to come to the rescue of standard victims or endangered objects. It is an indispensable tool to fire brigades, traffic departments, industrial and mining organizations and other facilities.

Features of Hydraulic Rescue Telescopic Ram

1. Cylinder made of high strength lightweight alloy;
2. Both ends of the skid gear guarantees will not slip under stress;
3. Hold the top time-consuming short, to accelerate the rescue process;
4. Auxiliary equipment: ram carriage.

Parameter of Hydraulic Rescue Telescopic Ram

Working pressure	63Mpa(630.000bar)
Max. Extending force	110KN(11ton)
Closed Length	≤350mm
Extending stroke	180mm
Extension rod length I/II/III	100/175/275mm
Working range	350-1080mm
Weight	≤10kg
Size(LXWXH)	350X260X90mm

Pictures of Hydraulic Rescue Telescopic Ram

HYF2 Negative Pressure Emergency Breathing Apparatus

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1579

Introduction of HYF2 Negative Pressure Emergency Breathing Apparatus

HYF2 isolated negative pressure oxygen breathing apparatus is the use of compressed oxygen isolated regenerative oxygen respirator, mainly for personal protection and accident handling in the harmful gases environment. It is widely used in mining, metallurgy, chemical, fire, oil, tunnel, subway, water company, grain storage and other departments, in toxic and harmful gas environment for emergency rescue personnel to provide respiratory protection for accident treatment or prevention.

1)Professional supplier;
2)Less resistance;
3)Much longer work time

Parameter of HYF2 Negative Pressure Emergency Breathing Apparatus

Model	HYF2
1. The main technical parameters
(1) Oxygen bottle	19.61 Mpa 200L oxygen storage
(2)  Oxygen supply ration	1.3~1.1L/min
(3) Automatic exhaust pressure	+196~294Pa
(4) Automatic supply pressure	-147~-245Pa
(5) Effective use time	2h
2. Dimensions and weight
(1) Weight	(including oxygen and absorbent) no more than 7kg
(2) Overall dimension	no more than 345*345*190 mm

Pictures of HYF2 Negative Pressure Emergency Breathing Apparatus

DJQ-I Single-edge Railway Chamfering Tool

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1519

Introduction of DJQ-I Single-edge Railway Chamfering Tool

a.max.chamfering diameter: 32

b.chamfering max. cutting torque: Tmax=10N.m

DJQ-I Single-edge Railway Chamfering Tool for eliminating stress concentration of sharp position after drilling rail.

Parameter of DJQ-I Single-edge Railway Chamfering Tool

a.max.chamfering diameter	Φ32
b.chamfering max. cutting torque	Tmax=10N·m
c.handle max.moving force	Fmax=55N (L=180mm)
d.working efficiency	a chamfer/10s
e.dimension	180×50×190
f.total weight	1kg

Pictures of DJQ-I Single-edge Railway Chamfering Tool

Emergency Hydraulic Rescue Spreader

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1642

Introduction of Emergency Hydraulic Rescue Spreader

Emergency Hydraulic Rescue Spreader is special rescue tool for spreading obstacles in road accident, earthquake and other circumstances, it can be connected with both hydraulic motor pump and hydraulic hand pump, different works, including spreading, clamping and pulling, can be carried out by it.

Features of Emergency Hydraulic Rescue Spreader

1,650mm expansion distance can tear steel for rescue channels

2,Short opening and closing time to accelerate rescue process

3,Bi-directional hydraulic lock and automatic reset valve, high security operation, combined with self-locking function, can expand in any position without retraction

4,Handle convenient operation, moving parts has protecting cover to ensure operators security

5,Can work with chain traction

Parameter of Emergency Hydraulic Rescue Spreader

Max. spreading distance	>720mm
Rated  working pressure	720Mpa
Max.spreading force	14.7t
Weight	18.8kgs

Pictures of Emergency Hydraulic Rescue Spreader

2h Oxygen Negative Pressure Portable Rebreather

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1578

Introduction of 2h Oxygen Negative Pressure Portable Rebreather

Respiratory airflow alternately run for the positive and negative pressure, breathing resistance is small, pressure reducer, counterflow.
Assembling of oxygen for quantitative oxygen valve, automatic supply valve, manual supply valves, pressure reducing valves, safety valves, emergency switch focus to design into one, compact, easy disassemble and maintenance.
Equipped with a row of saliva in the mouth with the pump, the saliva can always be ruled out.

Parameter of 2h Oxygen Negative Pressure Portable Rebreather

1. The main technical parameters
(1) Oxygen bottle	19.61 Mpa 200L oxygen storage
(2)  Oxygen supply ration	1.3~1.1L/min
(3) Automatic exhaust pressure	+196~294Pa
(4) Automatic supply pressure	-147~-245Pa
(5) Effective use time	2h
2. Dimensions and weight
(1) Weight	(including oxygen and absorbent) no more than 7kg
(2) Overall dimension	no more than 345*345*190 mm

Pictures of 2h Oxygen Negative Pressure Portable Rebreather

Portable YG Rail Transport Railway Device

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1518

Introduction of Portable YG Rail Transport Railway Device

1:ISO9001
2:PATENT
3:CRCC
Portable YG Rail Transport Railway Device is used for carrying rail.

Features of Portable YG Rail Transport Railway Device

1:Simple structure light weight,
2:easy to use,
3:transport rail flexible and reliable

Parameter of Portable YG Rail Transport Railway Device

1.load capacity	1~1.4T
2.dimension	2180×130×1040
3.weight	22kg

Pictures of Portable YG Rail Transport Railway Device

PHYM Fire Fighting Equipment Foam Bladder Tank

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1635

Introduction of PHYM Fire Fighting Equipment Foam Bladder Tank

PHYW fire fighting equipment foam bladder tank is composed of foaming tank, pressure type proportional mixer,inlet pipe,outlet pipe and control valve etc.When the pressure flow goes through the proportional mixer of this device,the water and foam can be auto mixed according to a certain proportion and the foam mixture will be output and provided to the foam generator and spray equipment to produce spray air foam for fire extinguishing.This device has two types:vertical and horizontal.The membranous device features a rubber made capsule in the stouage tank and the foam liquids,it is especially suitable for aqueous film foam liquids.Besides,the residue foam liquid is good for future use after fire extinguishing.This device enjoys the advantages of safety,reliability and high fire extinguishing efficiency.It is suitable for application in important locations such as petroleum enterprises,oil depots,oil terminals and airports etc.

Parameter of PHYM Fire Fighting Equipment Foam Bladder Tank

Type	Mixer Flow Rate L/S	Working Pressure (Mpa)	Foaming Liquid Tank Volume	Mixing Ratio %	Pressure Fall %
PHZY(M)32	4-32	0.6-1.2	0.8, 1.0 ,1.5, 2.0 ,2.5, 3.0	3or6	≤20
PHZY(M)L32	4-32		0.5, 0.7, 0.8 ,1.0, 1.5 ,2.0, 2.5, 3.0
PHZY(M)64	16-64		2.0 ,3.0, 4.0 ,5.5, 7.6 ,10.0
PHZY(M)L64	16-64		2.0, 3.0, 4.0, 5.5, 7.6 ,10.0
PHZY(M)80	24-80		2.0, 3.0 ,4.0, 5.5 ,7.6 ,10.0
PHZY(M)L80	24-80		2.0, 3.0 ,4.0 ,5.5 ,7.6 ,10.0
PHZY64x2	32-128		10.0 ,13.0, 18.0, 25.0
PHZY80x2	48-160		10.0, 13.0, 18.0, 25.0

Pictures of PHYM Fire Fighting Equipment Foam Bladder Tank

ADY6 Negative Pressure Oxygen Respirator

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1577

Introduction of ADY6 Negative Pressure Oxygen Respirator

ADY6 Negative Pressure Oxygen Respirator is a kind of personal respiratory protection device that uses compressed oxygen as air source, it is isolated and regenerative. Respiratory isolate with the outside world when the user breathing, instrument and human respiratory system form the inner loop. High pressure gas cylinder provides oxygen gas. Breathing gas was storage by airbag. It has high safety factor for human respiratory protection. Mainly used for the poisonous and harmful, oxygen and other disasters (normal atmospheric pressure) in the environment to implement rescue and relief.

Features & Benefits of ADY6 Negative Pressure Oxygen Respirator

• Masks to wear comfortable, clear vision, no fog, no frost
• Stable and reliable performance, simple operation.
• Manual drainage device, advanced exhaust function
• Breathing tube for large cross-section of high quality rubber hose, texture soft, with the head swinging at ease.

Applications of ADY6 Negative Pressure Oxygen Respirator

• Coal Mine
• Chemical Industry
• Metallurgy
• Petroleum
• Water Works
• Underground Construction
• Lab

Parameter of ADY6 Negative Pressure Oxygen Respirator

Oxygen supply ration:	1.4±0.1 L/min
Automatic oxygen supply ration:	≥100 L/min
Manual oxygen supply ration:	≥80 L/min
Automatic exhaust pressure:	-98~-294 pa
Inhaling concentrations of carbon dioxide:	≤2%
Inhaling oxygen concentration:	≥25%
Automatic exhaust pressure:	98-294Pa
Service time:	4 hours (medium labor intensity0
Oxygen bottle rated working pressure:	20 MPa
Oxygen bottle volume:	2 L
Oxygen storage:	400 L
Calcium hydroxide:	≥1 kg
Size:	455*375*165mm
Weight:	≤12.8kg (without calcium hydroxide,oxygen)

Pictures of ADY6 Negative Pressure Oxygen Respirator

Universal Track Cross Level and Gauge Measurement Ruler

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1517

Introduction of Universal Track Cross Level and Gauge Measurement Ruler

High Efficiency Universal Track Cross Level and Gauge Measurement Gauge Ruler  (feet), which is used for measuring the rail line between the two strands of rail gauge, levelness and super special measuring instruments.

Parameter of Universal Track Cross Level and Gauge Measurement Ruler

JTGC-1A aluminium alloy fold gauging rule	1610×196×524 ≤2.5kg
JTGC-3A Aluminum alloy work gauging rule ( Has a high board )	1660×106×55  ≤2.3kg
MTGC-3  woodiness gauging rule	1600×80×55   ≤2.2kg
MTGC-4woodiness gauging rule  ( Has a high board )	1600×80×55   ≤2.2kg
ZJTGC-6 Aluminum alloy narrow gauge 600 feet	765×93×30    ≤1.1kg
ZJTGC-7 Aluminum alloy narrow gauge 762 feet ( Has a high board )	915×96×55    ≤1.2kg
ZJTGC- Aluminum alloy narrow gauge 900 feet ( Has a high board )	1070×93×55   ≤1.4kg
JTGC-1000 1000mm aluminium alloy gauging rule	1610×196×524 ≤2.5kg
JTGC-1000W 1000mm magna gauging rule	1660×106×55  ≤2.3kg
JTGC-GC  Ultra high board gauging rule	1660×106×55  ≤2.3kg
JTGC-GBJ  Compensating  magna gauging rule	1660×106×55  ≤2.3kg

Pictures of Universal Track Cross Level and Gauge Measurement Ruler

Automatic Firefighting Water Monitor

Click below office website can knew more retails about product
http://www.railroadmachinery.com/productinfo1640

Introduction of Automatic Firefighting Water Monitor

Automatic firefighting water monitor is the infrared sensor technology, signal processing communication technology, control technology, computer technology and mechanical technology organically unifies in together, can automatically monitor the fire within the scope of protection. Once the fire happens, fire extinguishing device immediately start, Intelligent scanning of fire source in horizontal and vertical direction, after determine fire two range, the central controller issued a directive, fire alarm signal is sent out, at the same time start the water pump, open the valve, fire extinguishing device for aiming put out the fire, after put out the fire, the central controller issued a directive stop jetting water. If there is a new fire, the fire distinguish device will repeat the process, until all the fire was put out to return to the monitoring state. 5L/s~10L/s full automatic fire monitor water jet form columnar water jet, for range, large scope of protection, extinguishing ability is very strong.

Features of Automatic Firefighting Water Monitor

Using dual band infrared and ultraviolet composite detection technology, find the fire early, high accuracy, wide range, without blind spots;
The position of the fire source can be fixed point and the positioning of the water spray fire extinguishing, and the efficiency of the early fire is high;
In fire scene, through 485 bus can manual control the water jetting direction of fire extinguish device nozzle
Using bus system image transmission technology , combined with the field of color image signal remote manual control;
Meet the requirements of the national standard manual, automatic and remote manual control of the three ways;
Bus communication, less material consumption, convenient construction, maintenance is simple and convenient;
Secondary search, no reset, greatly shortens extinguishing time
Can receive any other manufacturers’ fire automatic alarm system linkage signal;
Light weight, compact in shape, generous and beautiful.

Parameter of Automatic Firefighting Water Monitor

Radius of Protection	30m	35m	60m
Water Jetting Flow	5L/s	10L/s	30L/s
Overall dimensions (LXWXH)	400mmx380mmx450mm	400mmx380mmx450mm	582mmx320mmx310mm
Weight	8KG	9KG	17KG
Interface diameter	DN32	DN32	DN80
Installation height	4-30m	4-30m	6-30m
Rated working pressure	0.6Mpa	0.6Mpa	0.6Mpa
Max. Working pressure	1.0Mpa	1.0Mpa	1.0Mpa
Voltage/Power	AC220V/Monitoring:1W, scan:50W	AC220V/Monitoring:1W, scan:50W	AC220V/Monitoring:1W, scan:50W
Communication mode	RS485(communication with field area controller)	RS485(communication with field area controller)	RS485(communication with field area controller)
The fire location time	≤30s	≤30s	≤35s
Working environment temperature	-20℃~80℃	-20℃~80℃	-20℃~80℃
Horizontal rotation range	0~360°(adjustable)	0~360°(adjustable)	0~360°(adjustable)
Vertical rotation range	-10°~+90°	-10°~+90°	-70°~+90°
Jet water mode	Reciprocating swing after straight injection	Reciprocating swing after straight injection	Reciprocating swing after straight injection

Pictures of Automatic Firefighting Water Monitor
